1:use widely
2:With motor flange,
3:High quality
4:reasonable price and low noise.
About us
Hangzhou Superior Transmission Machinery Co., Ltd., founded in 2003, has been producing high quality and high stability reduction gears.
We strive to be China’s best manufacturer of transmission equipment. Our target is to provide China’s enterprises with the best transmission system solution and service. Although difficult, we view it as our interest will actively realize it.
Our company is located beside the beautiful Qiantang River Bank, 7km away from Xiaoshan International Airport and 200km from Shanghai International Port. For superior commercial and production environment, this area is promoting the economic development of China and other regions around the world. We are lucky in this area and at the forefront of China’s development.
Features
1.widely used intubines,shaft liners and axletrees,goog resistance to wear,with precision in dimensions,low noise,advanced centric running castings.
2.with air vent and high precisio.
3.the structure is compact and the weight is large.
General Technical data
| Input Power(KW) of WP.WPK.WPW.WPWK(A.S.X.O.T.V) |
| speed of input shaft:1500r/min, without motor flange |
| RATIO | 10 | 15 | 20 | 25 | 30 | 40 | 50 | 60 |
| MODEL | | | | | | | | |
| 40 | 0.44 | 0.33 | 0.26 | 0.24 | 0.24 | 0.18 | 0.15 | 0.12 |
| 50 | 0.7 | 0.52 | 0.42 | 0.37 | 0.34 | 0.27 | 0.25 | 0.2 |
| 60 | 1.1 | 0.85 | 0.76 | 0.75 | 0.65 | 0.45 | 0.4 | 0.36 |
| 70 | 1.75 | 1.4 | 1.1 | 0.95 | 0.85 | 0.68 | 0.62 | 0.52 |
| 80 | 2.45 | 1.82 | 1.35 | 1.33 | 1.28 | 0.82 | 0.85 | 0.76 |
| 100 | 3.9 | 3.2 | 2.7 | 2.15 | 2.32 | 1.85 | 1.5 | 1.08 |
| 120 | 6.6 | 4.6 | 3.9 | 3.5 | 3.5 | 2.4 | 2.1 | 1.8 |
| 135 | 10.1 | 7.85 | 6.3 | 4.8 | 5.2 | 3.8 | 2.9 | 2.5 |
| 147 | 11.2 | 8.7 | 6.9 | 5.5 | 6 | 4.3 | 3.5 | 2.9 |
| 155 | 14.1 | 10.4 | 7.5 | 6.05 | 6.6 | 4.8 | 4 | 3.3 |
| 175 | 20.3 | 14.5 | 11.5 | 8.25 | 9.2 | 6.5 | 5.1 | 4.6 |
| 200 | 23.2 | 48.6 | 14.2 | 10.5 | 10.7 | 8.7 | 8.7 | 5.8 |
| 250 | 40.1 | 30.2 | 23.6 | 18.8 | 21.5 | 15.4 | 11.2 | 9.5 |
| Input Power(KW) of WP.WPK.WPW.WPWK(A.S.X.O.T.V) |
| speed of input shaft:1500r/min, with motor flange |
| RATIO | 10 | 15 | 20 | 25 | 30 | 40 | 50 | 60 |
| MODEL | | | | | | | | |
| 40 | 0.18 | 0.33 | 0.18 | 0.24 | 0.18 | 0.12 | 0.12 | 0.12 |
| 50 | 0.18 | 0.52 | 0.18 | 0.37 | 0.18 | 0.18 | 0.18 | 0.18 |
| 60 | 0.37 | 0.37 | 0.37 | 0.37 | 0.37 | 0.37 | 0.37 | 0.37 |
| 70 | 0.75 | 0.75 | 0.75 | 0.75 | 0.75 | 0.75 | 0.75 | 0.75 |
| 80 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 0.75 | 0.75 | 0.75 |
| 100 | 2.2 | 2.2 | 2.2 | 2.2 | 2.2 | 1.5 | 1.5 | 1.5 |
| 120 | 3 | 3 | 3 | 3 | 3 | 2.2 | 2.2 | 2.2 |
| 135 | 4 | 4 | 4 | 4 | 4 | 3 | 3 | 3 |
| 147 | 4 | 4 | 4 | 4 | 4 | 3 | 3 | 3 |
| 155 | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 |
| 175 | 7.5 | 14.5 | 11.5 | 8.25 | 9.2 | 6.5 | 5.1 | 4.6 |
